Manufacturing and sale of industrial doors, overhead crane doors, polyethylene doors
Choose the versions of our roller shutters: they represent a sturdy and reliable closure, suitable for factories and businesses!
Industrial roller shutters are the ideal closure for any company's logistical needs, designed for maximum reliability, robustness and safety.
Thanks to the small number of components used in their construction, industrial roller shutters take up little space as they roll up compactly and require little maintenance.
Industrial roller shutters are available in both steel and aluminium, and guarantee excellent durability thanks to the high quality standards of the raw materials used.
KEY STRENGHT
The double-sided polyurethane-filled profile allows for minimal external heat loss, ensuring maximum energy savings.
APPLICATIONS
- Logistics
- Industrial and commercial factories
- Storage areas
- Warehouses
- Loading and unloading areas
ROLLER SHUTTERS INFORMATION SHEET
-
Roller shutters information sheetRoller shutters information sheet
-
Roller shutters galleryRoller shutters gallery
INDUSTRIAL ROLLING SHUTTERS
AVAILABLE VERSIONS
OCM INDUSTRIAL ROLLING SHUTTERS
In-house production
Our products are designed and manufactured entirely in Italy at our Biella factory.
Team of Engineers
Team of engineers, designers and specialised technicians at your service to propose the best solutions.
Network of Agents
A network of agents in Italy and abroad is constantly expanding.
TECHNICAL FEATURES
- double steel-insulated profile
- double aluminium insulated profile
- single aluminium profile
Profiles guarantee high strength, high performance in terms of thermal and acoustic insulation and quiet operation.
Runners are machine profiled, the material is galvanised or powder-coated (optional)
- Maximum height: 12 m
- Hole size: 27 mm (large) / 10 mm (small)
Load capacity: 500 kg to 1400 kg
A fundamental element for roller shutter operation.
- Diameter: from ⌀ 133 to ⌀ 323,9
- Thickness: from 4 mm to 8 mm
Flanges welded on both sides to support the shaft itself.
QC500 model (power supply 400 Vac three-phase 50 Hz)
Door equipped with all useful elements for quick and easy installation.
Doors can be fitted with the following optional accessories:
- REMOTE CONTROL: a radio receiver with one or more hand-held transmitters to open one or more doors;
- RADAR: microwave motion device with adjustable options;
- METAL DETECTOR: with one or more coils below the transit floor connected to a sensor that detects metal objects and opens the door;
- PHOTOCELL: placed at a certain distance from the door, it generates an opening command when obscured;
- PUSH BUTTON: for pedestrian opening to partially open the door. Available at an extra cost: ‘mushroom’ push button, double push button, triple push button, contactless push button ‘magic switch’;
- PULL SWITCH: long galvanised steel arm with high mechanical strength;
- BADGE SYSTEM READER FOR ACCESS CONTROL AND DOOR OPENING: available in magnetic card or tag versions;
- INDUSTRIAL TRAFFIC LIGHT: with red and green LED lights.
Doors comply with effective regulations, in particular with European standard EN 13241 and are CE-marked.
COLOURS
Rolling shutters are available in a wide range of powder-coated colours that guarantee high weather resistance.
- RAL 1013 White
- RAL 3000 Red
- RAL 5010 Blue
- RAL 6005 Green
- RAL 7015 Grey
- RAL 7016 Grey
- RAL 8014 Brown
- RAL 8017 Brown
- RAL 9002 Grey white
- RAL 9006 Aluminium
- RAL 9007 Aluminium
- RAL 9016 White
- Light wood-like
- Dark wood-like
- Zinc-coated
ADVANTAGES
Why install industrial rollING shutters
Energy savings and
workflow optimization
Maximum reduction of heat loss thanks to the double-sided profile with polyurethane foam.
Silent operation
Maximum silence and safety.
Minimum space
Minimal space due to compact rolling behind the lintel.
Customization
Wide range of colours to meet all Customer requirements.
